TL;DR: To fix your iPhone 15 screen, you must replace the entire display assembly using a precision screwdriver set, a suction cup, and a heat source—there’s no glass-only repair. Follow the steps below to safely swap the screen in about 45 minutes, and always back up your device first.
Step 1: Prepare Your Workspace and Tools
Turn off your iPhone 15 and place it on a clean, soft cloth. Gather a P2 pentagon screwdriver, a Y000 tri-wing screwdriver, a suction cup, a plastic opening pick, a heat gun or hair dryer, and a replacement screen specifically for the iPhone 15 (with adhesive pre-installed). Also have a magnetic mat or small cups to keep screws organized—they are tiny and easy to lose.
If you want to dig deeper, check out our guide on Do Health Insurance Plans Cover High ER Bills? Here’s What Y.
Step 2: Remove the Two Bottom Screws
Using the P2 screwdriver, remove the two pentagon screws flanking the Lightning/USB-C port at the bottom edge. Put them aside. These are the only screws visible from the outside. Do not force them—if they strip, stop and apply more downward pressure.
Step 3: Heat and Open the Display
Apply heat to the bottom edge of the phone for 60–90 seconds using a heat gun on low or a hair dryer on high. This softens the adhesive. Place the suction cup near the bottom edge (just above the charging port) and pull firmly while sliding an opening pick into the gap. Work the pick around the edges, cutting the adhesive. Do not insert the pick deeper than 2–3 mm—you’ll hit the battery or display cables.
Step 4: Carefully Flip Open the Screen
Once the adhesive is cut, lift the screen from the bottom edge like a book, pivoting from the top. Do not yank it—there are flex cables connecting it to the logic board. Rest the screen against a book or stand at a 90-degree angle. You’ll see a metal bracket covering the battery and display connectors.
Step 5: Disconnect the Battery and Display Cables
Use the Y000 screwdriver to remove the three screws securing the metal bracket near the top of the logic board. Lift the bracket off. Then, using a plastic pick, gently disconnect the battery connector first (top-right), then the three display cables (touch, OLED, and ambient light). Wait 30 seconds after disconnecting the battery to avoid any power surge.
Step 6: Transfer the Front Camera and Ear Speaker
Your replacement screen does not include the front camera, ear speaker, or Face ID sensor. Use the Y000 screwdriver to remove the small brackets holding these components on the old screen, then transfer each to the new screen. This is the most delicate step—do not touch the sensor contacts with bare fingers. If you break the Face ID flex, Face ID will permanently fail.
Step 7: Reconnect and Test Before Sealing
Snap the three display cables into the new screen’s connectors, then reconnect the battery. Press the screen down gently, but do not seal it yet. Power on the phone and test the touch, brightness, True Tone, and Face ID. If everything works, power off, disconnect the battery, and secure the bracket with the three screws.
Step 8: Seal and Final Assembly
Remove the plastic backing from the adhesive on the new screen. Align the top edge first, then press down firmly along all edges for 30 seconds. Reinstall the two bottom screws. Wipe away any fingerprints with a microfiber cloth. Let the adhesive cure for at least one hour before heavy use.
FAQ
Q: Can I replace just the glass on my iPhone 15 instead of the whole screen?
A: No. The iPhone 15 uses an “OLED sandwich” where the glass, touch layer, and display are fused. Separating them requires a laser machine and risks permanent
